Features
• Single Supply with Operation down to 1.7V for 24AA04 and 24FC04
Devices, 2.5V for 24LC04B Devices
• Low-Power CMOS Technology: - Read current 1 mA, maximum - Standby
current 1 µA, maximum (I-temp.)
• Two-Wire Serial Interface, I2C Compatible
• Schmitt Trigger Inputs for Noise Suppression
• Output Slope Control to Eliminate Ground Bounce
• 100 kHz, 400 kHz and 1 MHz Compatibility
• Page Write Time: 5 ms, Maximum
• Self-Timed Erase/Write Cycle
• 16-Byte Page Write Buffer
• Hardware Write-Protect
• ESD Protection >4,000V
• More than 1 Million Erase/Write Cycles
• Data Retention >200 Years
• Factory Programming Available
• RoHS Compliant
• Temperature Ranges: - Industrial (I): -40°C to +85°C - Extended
(E): -40°C to +125°C
• Automotive AEC-Q100 Qualified.
Description The Microchip Technology Inc. 24XX04(1) is a 4-Kbit
Electrically Erasable PROM (EEPROM). The device is organized as two
blocks of 256 x 8-bit memory with a two-wire serial interface. Its
low-voltage design permits operation down to 1.7V with standby and
active currents of only 1 µA and 1 mA, respectively. The 24XX04
also has a page write capability for up to 16 bytes of data.
| Product name:24AA04T-I/OT |  |
| Manufacturer: Microchip | Product Category: Electrically Erasable Programmable Read-Only
Memory |
| Installation style: SMD/SMT | Package / Case: SOT-23-5 |
| Interface Type: 2-Wire, I2C | Storage capacity: 4 kbit |
| Organization: 512 x 8 | Supply Voltage - Min: 1.7 V |
| Supply Voltage - Maximum: 5.5 V | Minimum operating temperature: - 40 C |
| Maximum operating temperature: + 85 C | Maximum clock frequency: 400 kHz |
| Access time: 3.5 us | Data retention: 200 Year |
| Supply Current—Maximum: 3 mA | Series: 24AA04 |
| Brand: Microchip Technology | Height: 1.3 mm |
| Length: 3.1 mm | Operating supply current: 3 mA |
| Operating Supply Voltage: 1.8 V to 5.5 V | Product Type: EEPROM |
| Programming Voltage: 1.7 V to 5.5 V | Factory Packing Quantity: 3000 |
| Subcategory: Memory & Data Storage | Width: 1.8 mm |
| Unit weight: 23 mg | Package: Reel
Package: Cut Tape
Package: MouseReel |
