1 Features • No Direction-Control Signal Needed • Max Data Rates – 24 Mbps (Push Pull) – 2 Mbps (Open Drain) • Available in the Texas Instruments NanoFree™ Package • 1.65 V to 3.6 V on A port and 2.3 V to 5.5 V on B port (VCCA ≤ VCCB) • No Power-Supply Sequencing Required – VCCA or VCCB Can Be Ramped First • Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II • ESD Protection Exceeds JESD 22 – A Port • 2000-V Human-Body Model (A114-B) • 200-V Machine Model (A115-A) • 1000-V Charged-Device Model (C101) – B Port • 15-kV Human-Body Model (A114-B) • 200-V Machine Model (A115-A) • 1000-V Charged-Device Model (C101) • IEC 61000-4-2 ESD (B Port) – ±8-kV Contact Discharge – ±10-kV Air-Gap Discharge.

2 Applications • Handset • Smartphone • Tablet • Desktop PC.

3 Description This 4-bit non-inverting translator uses two separate configurable power-supply rails. The A port is designed to track VCCA. VCCA accepts any supply voltage from 1.65 V to 3.6 V. VCCA must be less than or equal to VCCB. The B port is designed to track VCCB. VCCB accepts any supply voltage from 2.3 V to 5.5 V. This allows for low-voltage bidirectional translation between any of the 1.8-V, 2.5-V, 3.3-V, and 5-V voltage nodes. When the output-enable (OE) input is low, all outputs are placed in the high-impedance state. The TXS0104E is designed so that the OE input circuit is supplied by VCCA. To ensure the high-impedance state during power up or power down, OE should be tied to GND through a pulldown resistor; the minimum value of the resistor is determined by the current-sourcing capability of the driver.
