    Fast Recovery Dual Channel Mosfet 250 C/10 Seconds At Terminals

    Ask Lasest Price
    Brand Name : OTOMO
    Certification : RoHS、SGS
    Price : Negotiated
    Delivery Time : 1 - 2 Weeks
    Payment Terms : L/C T/T Western Union
    Supply Ability : 18,000,000PCS / Per Day
    Model Number : RS3A THRU RS3M
    • Product Details
    • Company Profile

    Fast Recovery Dual Channel Mosfet 250 C/10 Seconds At Terminals

    RS3A THRU RS3M SURFACE MOUNT FASTRE COVERY RECTIFIER


    FEATURE
    The plastic package carries Underwriters Laboratory
    Flammability Classification 94V-0
    For surface mounted applications
    Low reverse leakage
    Built-in strain relief,ideal for automated placement
    High forward surge current capability
    High temperature soldering guaranteed:
    250 C/10 seconds at terminals
    Glass passivated chip junction
    MECHANICAL DATA
    Case : JEDEC DO-214AC molded plastic body over passivated chip
    Terminals : Solder plated, solderable per MIL-STD-750,
    Method 2026
    Polarity : Color band denotes cathode end
    Mounting Position : Any
    Weight :0.003ounce,0.093grams
    MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

    Ratings at 25 C ambient temperature unless otherwise specified.Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
    Note:
    1. Reverse recovery condition IF=0.5A,IR=1.0A,Irr=0.25A
    2. Measured at 1MHz and applied reverse voltage of 4.0V D.C.
    3. Thermal resistance from junction to ambient at 0.375”(9.5mm)lead length,P.C.B. mounte
    ,
